Opti-Pac 2100 Plus OF is a higher performing, low-fouling film fill media with vertically offset flutes manufactured from rigid corrugated PVC sheets for counterflow cooling tower heat-transfer applications. The fill modules are solvent-welded for maximum strength and are resistant to UV, rot, fungus, organic / inorganic acids, alkalis, and chemicals normally found in cooling tower water.
The principle of operation of cooling tower fill is to put as much water surface area in contact with as much air as possible, for the longest amount of time possible. Film fills allow the water to form thin flowing sheets to expose as much water surface area as possible to the interacting flow.
Cooling tower sheet fills or media, come in many different forms and “micro-structures,” each having unique characteristics to fit various applications. Film fills are selected for direct replacement, performance enhancement, and water condition compatibility. Each fill has performance characteristics that allow selections to be made for various heat loads, flow rates, water quality, and horsepower combinations.
Film fill designs include:
Modules are fabricated in 12", 24" and 48” depths, 12” to 24” widths, and in lengths up to 12’-0” in 2’ increments. Sheet spacing is 21mm and minimum heat transfer area (wetted surface) is 45 ft2/ft3. Standard PVC sheet mil thicknesses are 10 and 15 mil (after forming). Weight per cubic foot is approximately 1.6 lbs/ft3 for 10-mil packs and approximately 2.4 lbs/ft3 for 15-mil. Custom dimension modules and mil thicknesses are available upon request.
| Name | File Size | Type | Language |
|---|---|---|---|
| Opti-Pac 2100 Plus OF Media | 66.12 KB | Specification Sheet | English |
